Yamaha - XT 550 28E - 5Y3 (Italian Market) 82

default bike image Do you have any images of this bike? Upload them here

Bike Info

CC:
550
Chassis info:
5Y3
XT 550 28E - 5Y3 (Italian Market) Parts and accessories

Service

Engine Oil Classification API:
SE
Engine Oil Grade SAE:
20W40
Engine Oil quantity (litres):
2.2
Engine Oil quantity with filter (litres):
1.9
Fork oil grade:
10
Front Fork Oil cc (left leg):
369
Front Fork Oil cc (right leg):
369
Spark Plugs Gap (mm):
0.6-0.7
Tyre Pressure Back Bar / psi:
1.5/21
Tyre Pressure Front Bar / psi:
1.5/21

Brakes

Front:
Drum
Rear:
Drum
Front Drum Size:
150
Rear Drum Size:
150

Dimensions

Dry Weight:
138 Kg
Fuel Capacity:
14 Litres
Ground Clearance:
250 mm
Height:
1180 mm
Length:
2260 mm
Reserve Fuel Capacity:
2.0 Litres
Seat Height:
860 mm
Wet Weight:
145 Kg
Wheelbase:
1400 mm
Width:
860 mm

Electrics

Voltage:
12v
Battery:
12N5-3B - 12V 15Ah
Bulb-Headlight:
12V 60/55W
Ignition:
CDI
Spark Plugs:
D7EA

Engine

Type:
Air Cooled 4 Stroke SOHC Single
Air Filtration:
wet element
Bore x Stroke:
92 x 84 mm
Carburation:
Y26PV/TK Tikaki - YDIS
Carburation Idle Jet:
42
Carburation Main Jet:
130 - 130
Compression Ratio:
8.5:1
Displacement:
558cc
Lubrication System:
dry sump
No. of Valves:
4
Starting:
Kick

Transmission

Chain Number of Links:
97
Chain type:
520DS
Clutch Type:
Multi-plate, wet
Final Drive:
Chain
Primary Drive:
chain
Primary Drive Ratio:
75-010/126
Sprocket front:
15
Sprocket rear:
39
Transmission:
5 Speed

Power

Max Power Output:
38 Hp

Suspension

Front:
Telescopic fork
Front Travel:
205mm
Rear:
monoshock
Rear Travel:
100mm

Tyres

Front:
3.00-21-4PR
Rear:
4.60-18-4PR

Wheels

Front:
1.60x21
Rear:
2.15x18
