Spec Sheet
The information below is specific to the Yamaha - XV 750 Virago 94, showing anything for service information to the amount of fork oil or even the tyre pressures. If you would like to contribute any missing information, please use the edit link below.
Back.Bike Info
CC:
750
Service
Engine Oil quantity with filter (litres):
3.6 Litres
Brakes
Front:
Twin Disc
Rear:
Drum
Front Disc Size:
267mm
Front-Pistons-per-caliper:
2
Rear Drum Size:
200mm
Dimensions
Dry Weight:
220 kgs
Fuel Capacity:
17 Litres
Reserve Fuel Capacity:
2.6 Litres
Seat Height:
715 mm
Wet Weight:
227 kg
Electrics
Voltage:
12v
Battery:
YB16AL
Bulb-Headlight:
12V 60/55W
Ignition:
Electronic
Spark Plugs (Iridium):
NGK BP7ES
Engine
Type:
Air Cooled 4 Stroke SOHC V Twin
Bore x Stroke:
83 x 69.2 mm
Carburation:
34mm Keihin carb
Compression Ratio:
8.7:1
Displacement:
748
No. of Valves:
4 - 2 per cylinder
Starting:
Electric
Transmission
Clutch Type:
Wet multi-plate type
Final Drive:
Shaft
Transmission:
5 Speed
Misc.
Exhaust:
2 into 2
Motorcycle Style:
CRUISER
Power
Max Power Output:
50.8 hp @ 7000 rpm
Max Torque:
5.4 kgf-m @ 5750 rpm
Standing 1/4 mile:
13.8 sec / 149.6 km/h
Top Speed:
178.8 km/h
Suspension
Front:
38mm Telescopic Forks
Rear:
Twin Shock Forked Swinging Arm
Tyres
Front:
100/90-H19 Tubeless
Rear:
140/90-H15 Tubeless
Add information to the model
