Spec Sheet
The information below is specific to the Kawasaki - KLV 1000 (LV 1000 A2H) 05, showing anything for service information to the amount of fork oil or even the tyre pressures. If you would like to contribute any missing information, please use the edit link below.
Back.Bike Info
CC:
1000
Brakes
Front:
Twin Disc
Rear:
Disc
Front Disc Size:
310 mm
Front-Pistons-per-caliper:
2
Rear Disc Size:
260 mm
Rear-Pistons-per-caliper:
1
Dimensions
Dry Weight:
208 kg
Fuel Capacity:
22 litres
Height:
1395 mm
Length:
2295 mm
Rake:
26.3°
Seat Height:
840 mm
Trail:
111 mm
Wheelbase:
1535 mm
Width:
910 mm
Electrics
Voltage:
12v
Engine
Type:
Liquid Cooled 4 Stroke DOHC V Twin
Bore x Stroke:
98.0 x 66.0 mm
Carburation:
Fuel Injection 2 x 45 mm Bore
Displacement:
996 cc
No. of Valves:
8
Transmission
Transmission:
6 Speed
Misc.
Frame:
Aluminion Twin-spar
Motorcycle Style:
Dual Sport/Adventure
Power
Max Power Output:
72.0 kW (98 PS)/7,600 rpm
Max Torque:
101 Nm (10.3 kgf·m)/6,400 rpm
Suspension
Front:
43mm Telescopic Forks
Front Travel:
160 mm
Rear Travel:
159 mm
Tyres
Front:
110/80-V19 Tubeless
Rear:
150/70-ZR17 Tubeless
