Spec Sheet
The information below is specific to the Kawasaki - A1 Samurai 69, showing anything for service information to the amount of fork oil or even the tyre pressures. If you would like to contribute any missing information, please use the edit link below.
Back.Bike Info
CC:
250
Service
Chain Freeplay mm:
25 mm
Front Fork Oil cc (left leg):
200
Front Fork Oil cc (right leg):
200
Spark Plugs Gap (mm):
0.6 mm
Brakes
Front:
Drum
Rear:
Drum
Front Drum Size:
180 mm
Rear Drum Size:
180 mm
Dimensions
Fuel Capacity:
13.51 liters (3.57 gallons)
Wet Weight:
158 kg - 350 lb
Electrics
Voltage:
12v
Battery:
YB9-B
Spark Plugs:
B8HS
Engine
Type:
Air Cooled 2 Stroke Parallel Twin
Bore x Stroke:
53.0 mm x 56.0 mm
Carburation:
dual rotary valve feeding two Mikuni ,s
Compression Ratio:
6.8:1
Displacement:
247 cc
Starting:
Kick
Transmission
Chain Number of Links:
92
Chain type:
525
Clutch Type:
Wet Multiplate
Final Drive:
Chain and Sprockets
Sprocket front:
15
Sprocket rear:
37
Transmission:
5 Speed
Misc.
Frame:
Double tubular steel cradle
Motorcycle Style:
Roaster
Place of Manufacture:
Japan
Power
Top Speed:
100 mph plus
Suspension
Front:
Telescopic hydraulic inner spring front forks
Rear:
Three-position spring preload adjustable Twin shock absorbe
