Honda - XR 125 L5 05

picture of bike Do you have any images of this bike? Upload them here

Bike Info

CC:
125
Chassis info:
9c2jd19a03r201115
XR 125 L5 Parts and accessories

Service

2 Stroke Tank - Litres:
No
Chain Freeplay mm:
20 - 30 mm
Engine Oil Classification API:
sg
Engine Oil Grade SAE:
10w/30
Engine Oil quantity with filter (litres):
0.9
Float Height:
14 mm
Fork oil grade:
10w
Front Fork Oil cc (left leg):
170
Front Fork Oil cc (right leg):
170
Idle Speed (rpm):
1400 - 1500
Spark Plugs Gap (mm):
0.8 - 0.9
Valve Clearance Cold - Exhaust:
0.08
Valve Clearance Cold - Inlet:
0.08

Brakes

Front:
Disc
Rear:
Drum
Brake fluid:
DOT4
Front Disc Size:
240mm
Front-Pistons-per-caliper:
2

Dimensions

Dry Weight:
118 kg
Fuel Capacity:
12 l
Height:
1.130 mm
Length:
2.105 mm
Reserve Fuel Capacity:
3.5 l
Width:
815 mm

Electrics

Voltage:
12v
Battery:
4 ah
Bulb-Headlight:
35 w 12v
Ignition:
CDI
Spark Plugs:
DPR8EA-9 NGK
Spark Plugs (Iridium):
X24EPR-U9

Engine

Type:
Air Cooled SOHC Single
Bore x Stroke:
56.5 x 49.5mm
Carburation:
22mm PD-type carburettor
Carburation Idle Jet:
38
Carburation Main Jet:
95
Displacement:
124 cc
Fuel Minimum Octane Rating:
91
No. of Valves:
2
Pilot Screw Setting:
1.75 - 2.00
Red line RPM:
8500

Transmission

Chain Number of Links:
132
Clutch Type:
wet
Sprocket front:
17
Sprocket rear:
54

Misc.

Motorcycle Style:
ENDURO ROAD/TRAIL

Power

Max Power Output:
8.3kw(11hp)@ 8500 rpm

Tyres

Front:
90/90-19 Tubed
Rear:
110/90-17 Tubed

Wheels

Bearing Front Left:
12x37x12mm
Bearing Front Right:
12x37x12mm
