Spec Sheet
The information below is specific to the Honda - Scoopy ACF110 11, showing anything for service information to the amount of fork oil or even the tyre pressures. If you would like to contribute any missing information, please use the edit link below.
Back.Bike Info
CC:
110
Service
Engine Oil quantity (litres):
0.7
Engine Oil quantity with filter (litres):
0.7
Brakes
Front:
Disc
Rear:
Drum
Front-Pistons-per-caliper:
1
Dimensions
Dry Weight:
94 kilos
Fuel Capacity:
3.5 litres
Ground Clearance:
150 mm
Height:
1070 mm
Length:
1844 mm
Wheelbase:
1240 mm
Width:
699 mm
Electrics
Voltage:
12v
Spark Plugs:
CPR8EA- 9
Engine
Type:
Air Cooled 4 Stroke SOHC Single
Bore x Stroke:
50 x 55 mm
Carburation:
PGM-FI electronic fuel injection
Compression Ratio:
9.2 : 1
Displacement:
108 cc
No. of Valves:
2
Starting:
Electric and Kick
Transmission
Transmission:
Auto V matic
Misc.
Motorcycle Style:
Scooter
Place of Manufacture:
Thailand
Suspension
Rear:
Monoshock
Tyres
Front:
80/90 - 14
Rear:
90/90 - 14
