Spec Sheet
The information below is specific to the Honda - H 100 SM 91, showing anything for service information to the amount of fork oil or even the tyre pressures. If you would like to contribute any missing information, please use the edit link below.
Back.Bike Info
CC:
100
Service
Fork oil grade:
Fork Oil or ATF
Front Fork Oil cc (left leg):
84
Front Fork Oil cc (right leg):
84
Gearbox Oil Litres:
0.85
Idle Speed (rpm):
1300
Tyre Pressure Back Bar / psi:
28
Tyre Pressure Back - Pillion Bar / psi:
32
Tyre Pressure Front Bar / psi:
24
Tyre Pressure Front - Pillion Bar / psi:
24
Brakes
Front:
Drum
Rear:
Drum
Dimensions
Dry Weight:
83.5kg
Fuel Capacity:
10 lit
Ground Clearance:
160mm
Height:
1020mm
Length:
1860mm
Reserve Fuel Capacity:
2.4 lit
Wheelbase:
1200mm
Width:
690mm
Electrics
Voltage:
6v
Main Fuse:
10A
Spark Plugs:
NGK BR8HS
Engine
Type:
Air Cooled 2 Stroke Reed Valve V Single
Bore x Stroke:
50.5 X 49.5
Compression Ratio:
7.2:1
Displacement:
99cm
Lubrication System:
Honda 2-stroke oil injection
Pilot Screw Setting:
1 1/8
Transmission
Chain Number of Links:
108
Final Drive:
Chain
Gearchange Pattern:
1 N 2 3 4 5
Gear Ratio 1st:
3.083 (37/12)
Gear Ratio 2nd:
1.882 (32/17)
Gear Ratio 3rd:
1.400 (28/20)
Gear Ratio 4th:
1.130 (26/23)
Gear Ratio 5th:
0.960 (24/25)
Sprocket front:
15
Sprocket rear:
36
Misc.
Motorcycle Style:
ROADSTER
Tyres
Front:
250-18 Tubed
Rear:
275-18 Tubed
