Spec Sheet
The information below is specific to the Honda - CBR 600 F2 02, showing anything for service information to the amount of fork oil or even the tyre pressures. If you would like to contribute any missing information, please use the edit link below.
Back.Bike Info
CC:
600
Service
Chain Freeplay mm:
25 - 35
Cooling System (litres):
3.00
Engine Oil Classification API:
SG
Engine Oil Grade SAE:
10W/40
Engine Oil quantity with filter (litres):
3.3
Fork oil grade:
10W
Front Fork Oil cc (left leg):
116
Front Fork Oil cc (right leg):
465
Idle Speed (rpm):
1300 - 1400
Spark Plugs Gap (mm):
0.8 - 0.9
Tyre Pressure Back Bar / psi:
36
Tyre Pressure Back - Pillion Bar / psi:
42
Tyre Pressure Front Bar / psi:
36
Tyre Pressure Front - Pillion Bar / psi:
42
Valve Clearance Cold - Exhaust:
0.25 - 0.31
Valve Clearance Cold - Inlet:
0.17 - 0.23
Brakes
Front:
Twin Disc
Rear:
Disc
Brake fluid:
DOT4
Front Disc Size:
276mm
Front-Pistons-per-caliper:
2
Rear Disc Size:
220 mm
Rear-Pistons-per-caliper:
1
Dimensions
Dry Weight:
170 Kg
Fuel Capacity:
18 litres
Ground Clearance:
135 mm
Height:
1130 mm
Length:
2060 mm
Reserve Fuel Capacity:
3 litres
Seat Height:
810 mm
Wet Weight:
197 Kg
Wheelbase:
1395 mm
Width:
685 mm
Electrics
Voltage:
12v
Battery:
YTZ10S
Spark Plugs:
IMR9A-9H
Engine
Type:
Liquid Cooled 4 Stroke DOHC Inline Four
Air Filtration:
Paper element
Bore x Stroke:
67.0 x 42.5mm
Displacement:
599 cc
Fuel Minimum Octane Rating:
95
Lubrication System:
forced ,wet sump
No. of Valves:
16
Red line RPM:
13500 rpm
Starting:
Electric
Transmission
Chain Number of Links:
108
Chain type:
DID 525HV
Final Drive:
Chain
Gearchange Pattern:
1-N-2-3-4-5-6
Sprocket front:
16
Sprocket rear:
45
Transmission:
6 speed
Misc.
Frame:
Aluminium twin spar
Insurance Group:
14
Motorcycle Style:
Sports
Power
Fuel Consumption:
38 - 42 mpg
Max Power Output:
80 kw (109bhp) @12500 rmp
Max Torque:
6.8 Kg - m (67Nm) @10500 rpm
Power/Weight Ratio:
553 Bhp / Tonne
Standing 1/4 mile:
11.5 secs
Top Speed:
155 mph
Suspension
Front:
telescopic forks
Front Travel:
120 mm
Rear:
swing arm pro-link
Rear Travel:
120 mm
Tyres
Front:
120/60-ZR17 Tubeless
Rear:
160/60-ZR17 Tubeless
