Spec Sheet
The information below is specific to the Honda - CB 750 K6 76, showing anything for service information to the amount of fork oil or even the tyre pressures. If you would like to contribute any missing information, please use the edit link below.
Back.Bike Info
CC:
750
Service
Engine Oil Classification API:
SE
Engine Oil Grade SAE:
10W40
Engine Oil quantity with filter (litres):
3.5
Fork oil grade:
ATF
Front Fork Oil cc (left leg):
15-160
Front Fork Oil cc (right leg):
15-160
Idle Speed (rpm):
1000
Valve Clearance Cold - Exhaust:
0.08 mm
Valve Clearance Cold - Inlet:
0.05 mm
Brakes
Front:
Disc
Rear:
Drum
Dimensions
Fuel Capacity:
17 litre
Electrics
Voltage:
12v
Spark Plugs (Iridium):
NGK DR8EIX
Engine
Type:
Air Cooled DOHC Straight Four
Bore x Stroke:
61 x 63 mm
Displacement:
736cc
No. of Valves:
8
Transmission
Chain Number of Links:
104
Sprocket front:
16
Sprocket rear:
48
Misc.
Motorcycle Style:
ROADSTER
Tyres
Front:
325-19 Tubeless
Rear:
400-18 Tubeless
Add information to the model
