Spec Sheet
The information below is specific to the Honda - 700 XL 700 VA Transalp, showing anything for service information to the amount of fork oil or even the tyre pressures. If you would like to contribute any missing information, please use the edit link below.
Back.Honda - XL 700 VA Transalp 10
Bike Info
CC:
700
Brakes
Front:
Twin Disc
Rear:
Disc
Front Disc Size:
256mm
Front-Pistons-per-caliper:
2
Rear Disc Size:
240mm
Rear-Pistons-per-caliper:
1
Dimensions
Dry Weight:
191 kg
Ground Clearance:
177mm
Height:
1305mm
Length:
2250mm
Seat Height:
841mm
Trail:
111 mm
Wheelbase:
1501mm
Width:
905mm
Electrics
Voltage:
12v
Engine
Type:
Liquid Cooled 4 Stroke SOHC V Twin
Bore x Stroke:
81mm x 66mm
Compression Ratio:
10:1
Displacement:
680cc
No. of Valves:
3 valves per cylinder
Valve Train:
SOHC
Transmission
Clutch Type:
Wet Multiplate
Final Drive:
Chain and Sprockets
Misc.
Frame:
A Semi-double cradle, steel box section
Motorcycle Style:
Dual Sport/Adventure
Place of Manufacture:
Spain
