Spec Sheet
The information below is specific to the Suzuki - GV 1200 GLG Madura 86, showing anything for service information to the amount of fork oil or even the tyre pressures. If you would like to contribute any missing information, please use the edit link below.
Back.Bike Info
CC:
1200
Chassis info:
JS1VV71L7G2100212
Brakes
Front:
Twin Disc
Rear:
Disc
Dimensions
Dry Weight:
245 kg
Fuel Capacity:
13 litre
Ground Clearance:
145 mm
Height:
1,215 mm
Length:
2,225 mm
Seat Height:
770 mm
Wheelbase:
1,575 mm
Width:
870 mm
Engine
Type:
Liquid Cooled 4 Stroke DOHC V Four
Air Filtration:
four Mikuni BDS carburetors (36 mm)
Bore x Stroke:
78,0 x 61,0 mm
Carburation:
4 x Mikuni BDS carburetors (36 mm)
Compression Ratio:
10.5:1
Displacement:
1165 cc
No. of Valves:
16
Transmission
Transmission:
6 Speed
Suspension
Front:
Air Assisted Forks
Rear:
Monoshock
Wheels
Front:
19 inch
Rear:
16 Inch
