Spec Sheet
The information below is specific to the Sukida - Patriot SK125-5 10, showing anything for service information to the amount of fork oil or even the tyre pressures. If you would like to contribute any missing information, please use the edit link below.
Back.Bike Info
CC:
125
Bike Description:
Engine Brand: Haojian
EEC Type Approval No.: e4*2002/24*1193*00
Brakes
Front:
Disc
Rear:
Drum
Dimensions
Ground Clearance:
203 mm
Height:
1115 mm
Length:
1990 mm
Seat Height:
780 mm
Wheelbase:
1270 mm
Width:
745 mm
Electrics
Voltage:
12v
Ignition:
CD1
Engine
Type:
Air Cooled 4 Stroke OHV Single
Bore x Stroke:
56.5 x 49.5mm
Displacement:
125 cc
No. of Valves:
2
Starting:
Electric / Kick Start
Transmission
Chain type:
428
Clutch Type:
Wet Multiplate
Final Drive:
Chain and Sprockets
Sprocket front:
15
Transmission:
5 speed
Misc.
Place of Manufacture:
China
Tyres
Front:
2.75-18
Rear:
110/90-16
