Spec Sheet
The information below is specific to the Kawasaki - VN 1500 N1 Classic Fi 00, showing anything for service information to the amount of fork oil or even the tyre pressures. If you would like to contribute any missing information, please use the edit link below.
Back.Bike Info
CC:
1500
Chassis info:
VNT50NNA-000001 - 009000
Brakes
Front:
Disc
Rear:
Disc
Brake fluid:
DOT 4
Dimensions
Dry Weight:
292 kg
Fuel Capacity:
19 litres
Rake:
32º
Seat Height:
700 mm (27,6 in)
Trail:
122 mm
Wheelbase:
1661 mm
Electrics
Voltage:
12v
Ignition:
Digital with K-TRIC
Spark Plugs:
NGK DPR6EA-9
Engine
Type:
Liquid Cooled 4 Stroke SOHC V Twin
Bore x Stroke:
102 x 90 mm
Carburation:
Keihin CVK40
Compression Ratio:
8.6:1
Displacement:
1470 cc
No. of Valves:
8
Starting:
Electric starter
Transmission
Clutch Type:
Wet multi plate
Final Drive:
Shaft
Gearchange Pattern:
1 N 2 3 4 5
Transmission:
5 speed with Neutral Positive Finder
Misc.
Colour Options:
Cosmic Splendor Red or Candy Cardinal Red/ Pearl Gently Gray
Frame:
Double-cradle, high-tensile steel
Motorcycle Style:
CRUISER
Suspension
Front:
41mm hydraulic telescopic fork
Rear:
Dual shocks with 5-way preload adjustment
Tyres
Front:
130/90-H16 Tubeless
Rear:
150/80-V16 Tubeless
Add information to the model
All information presented on the website is given to the best of our knowledge at the given time. All information is intended to only as a guide. A major Japanese manufacturer's quote:
We reserve the right to vary our specification with or without notice, and as such time and in such manner as we think fit.
