Honda - H 100 A 80

default bike image Do you have any images of this bike? Upload them here

Bike Info

CC:
100
H 100 A Parts and accessories

Service

Fork oil grade:
Fork Oil or ATF
Front Fork Oil cc (left leg):
113.5 - 118.5 cc
Front Fork Oil cc (right leg):
113.5 - 118.5 cc
Idle Speed (rpm):
1300
Tyre Pressure Back Bar / psi:
24
Tyre Pressure Back - Pillion Bar / psi:
28
Tyre Pressure Front Bar / psi:
24
Tyre Pressure Front - Pillion Bar / psi:
32

Dimensions

Dry Weight:
86kg
Fuel Capacity:
10 lit
Ground Clearance:
160mm
Height:
1040mm
Length:
1885mm
Reserve Fuel Capacity:
2.4 lit
Wheelbase:
1225mm
Width:
780mm

Electrics

Spark Plugs:
NGK BR7HS

Engine

Type:
Air Cooled 2 Stroke Single
Bore x Stroke:
50.5 X 49.5
Carburation Main Jet:
115
Compression Ratio:
6.7:1
Lubrication System:
Honda 2-stroke oil injection

Transmission

Chain Number of Links:
108
Clutch Type:
wet multiplate
Gear Ratio 1st:
3.083 (37/12)
Gear Ratio 2nd:
1.882 (32/17)
Gear Ratio 3rd:
1.400 (28/20)
Gear Ratio 4th:
1.130 (26/23)
Gear Ratio 5th:
0.960 (24/25)
Sprocket front:
15
Sprocket rear:
36

Misc.

Motorcycle Style:
ROADSTER

Tyres

Front:
250-18 Tubed
Rear:
275-18 Tubed
