Spec Sheet
The information below is specific to the Kawasaki - 250 KH 250 S1, showing anything for service information to the amount of fork oil or even the tyre pressures. If you would like to contribute any missing information, please use the edit link below.
Back.Bike Info
CC:
250
Service
Fork oil grade:
SAE 10W non-detergent
Front Fork Oil cc (left leg):
210cc / 375mm
Front Fork Oil cc (right leg):
210cc / 375mm
Gearbox Oil grade:
SAE 10W30 or 10W40
Gearbox Oil Litres:
1.1litres
Spark Plugs Gap (mm):
0.4 - 0.5
Tyre Pressure Back Bar / psi:
22 bar 31psi
Tyre Pressure Back - Pillion Bar / psi:
35psi
Tyre Pressure Front Bar / psi:
17 bar 24psi
Tyre Pressure Front - Pillion Bar / psi:
28psi
Brakes
Front:
Disc
Rear:
Drum
Brake fluid:
DOT 3
Front Disc Size:
279 mm
Rear Drum Size:
184 mm
Dimensions
Dry Weight:
163 kg
Fuel Capacity:
14.11 litres
Ground Clearance:
150 mm
Height:
1035 mm
Length:
2055 mm
Reserve Fuel Capacity:
2 litres
Seat Height:
762 mm
Wheelbase:
1385 mm
Width:
760 mm
Electrics
Voltage:
12v
Bulb-Headlight:
12V 35/35
Ignition:
3 sets of points
Spark Plugs:
NGK B9HCS
Engine
Type:
Air Cooled 2 Stroke Inline Triple
Bore x Stroke:
45 x 52.3mm
Carburation:
3 x 22mm Mikuni
Carburation Main Jet:
75
Compression Ratio:
7.5:1
Displacement:
249cc
Starting:
Kickstarter
Transmission
Chain Number of Links:
108
Clutch Type:
Wet multiplate
Final Drive:
Chain
Gear Ratio 1st:
2.86(40/14)
Gear Ratio 2nd:
1.79(34/19)
Gear Ratio 3rd:
1.35(31/23)
Gear Ratio 4th:
1.12(28/25)
Gear Ratio 5th:
0.96(26/27)
Sprocket front:
15
Sprocket rear:
48
Transmission:
5 speed constant mesh return speed
Misc.
Frame:
Tubular steel double cradle
Motorcycle Style:
ROADSTER
Power
Fuel Consumption:
36 mpg
Max Power Output:
26 bhp @7500rpm
Max Torque:
19 ft lb @ 7000rpm
Standing 1/4 mile:
15.8 sec
Top Speed:
88.75 mph
Suspension
Front:
34 mm telescopic forks
Rear:
Twin shocks
Tyres
Front:
325-S18 Tubed
Rear:
350-18 Tubed
Wheels
Front:
Spoked
Rear:
Spoked
